HES 5000 Series Grade 1 Electric Strike - Compact Electric Door Strike for Cylindrical Locksets
The HES 5000 Series Electric Strike is engineered for commercial and institutional openings where space behind the frame is limited. Its compact design and unique keeper pin locking mechanism allow the strike to exceed the strength ratings of many frames, doors, and locking hardware systems.
This field-selectable fail safe/fail secure electric strike accommodates latchbolts up to 5/8" throw and provides reliable operation in access control applications. Built to ANSI/BHMA Grade 1 standards and tested to one million cycles, the 5000 Series delivers dependable performance in demanding environments.
Key Features :
CLatchboltsign for narrow frame profiles
Grade 1 certified performance
Field selectable fail safe / fail secure
Accommodates latchbolts up to 5/8" throw
Cylindrical lockset compatible
Dynamic strength rating of 70 ft-lbs
Endurance tested to 1,000,000 cycles
Burglary resistant construction
Windstorm resistant
Outdoor rated
Dual voltage 12/24 VDC
PoE friendly
Latchbolt monitoring available
Certifications :
ANSI/BHMA A156.31 Grade 1
UL 294 Listed
UL 1034 Burglary Resistant Listed
ANSI/SDI 250.13 Certified
ASTM E330 Certified
RoHS Compliant
Suitable for Outdoor Use
Product Details
